Super Ultra-fine Mill

  • Max Feeding size: 20mm
  • Fineness: 325-2500 mesh
  • Capacity: 0.5-25 tph
  • Power: 150-590 kw
  • Product description: CXM series ultrafine mill is the equipment specializing in producing fine and superfine powder of non-inflammable, non-explosive and brittle materials with Mohs's hardness under six, such as calcite,
  • INQUIRY


Brief introduction of Super ultra-fine mill:

CXM series ultra-fine grinding mill is the equipment specializing in producing fine and superfine powder of non-inflammable, non-explosive and brittle materials with Mohs's hardness under six, such as calcite, chalk, limestone, dolomite, kaolin, bentonite and other more than 200 kinds of stone materials. The ultra-fine grinding mill mainly consist of main unit, classifier, powder collector, dust cleaner, blower, muffler, sound-proof room, crusher, bucket elevator, storage hopper, and vibrating feeder.



The features & benefits of Super ultra-fine Mill:

High Efficiency:
Under the same finished final size and the same motor power, the capacity of ultrafine grinding mill is twice as much as jet mill, mixing grinder and ball mill, and energy consumption decreased 30%.
Long life cycle of spare parts:
The ring and roller are forged by special steel material with high utilization, the lifetime can reach 2-5 years for grinding calcite carbonate.
High safety and reliability:
As no rolling bearings or screws in grinding cavity, there are no problems caused by bolts shedding or rapid wear of bearings and seal components.
High fineness, flexible adjustment:
The final fineness of the grinding materials can be adjusted between 250 meshes and 2500 mesh (74-5 micron), and the product fineness can reach D97≤5μm.
Environment-friendly:
The application of pulse bag filter and muffler greatly alleviates dust pollution and noise.
Advanced intelligent speed control device:

Convenient adjusting, more uniform particle size.



Working principle of Super ultra-fine Mill:

After crushed by hammer crusher, the large materials become small ones and are sent to storage hopper by elevator, and then evenly sent to the upper distribution plate of the turn plate by vibrating feeder and sloping feeding pipe. When the grinding mill is at work, the main bearing and each dial are driven by electromotor through reducer, and all the grinding rollers are rolling in the ring channels driving by dial through plunger. The materials are driven to the edge of the turn plate by the centrifugal force and fall down into the grinding chambers. The high-pressure air blower constantly inhales air, airflow with crushed materials are brought to classifier whose high-speed impeller will screen the airflow: The unqualified particle size will fall and return to the mill for being reground while the qualified particle size mixed with air will go into the cyclone powder collector. Most of the qualified powders will fall and exit from the discharging valve at the bottom; A small proportion of the fine powders, with airflow, moves to the dust cleaner. The materials from the above two lots are sent by the conveyor to get finished powders packed. In addition, filtered clean air will be emitted from muffler in the end.



Technical parameter of Super ultra-fine Mill:

Model

CXM800

CXM900

CXM1000

CXM1250

CXM1680

Ring diameter

800

900

1000

1250

1680

Ring number (pcs)

3

3

4

4

4

Roller number

18-21

24-32

28-36

30-44

30-40

Max feeding size (mm)

10

10

15

15

20

Fineness granularity (mesh)

325-2500

325-2500

325-2500

325-2500

325-2500

Capacity (kg/h)

500-4500

800-6500

1000-8500

2500-14000

5000-25000

Main motor power (kw)

75

45*2

132

185

315

Classifier motor power (kw)

18.5

18.5

30

15*4

18.5*5

Blower motor power (kw)

45

55

75

110

90*2

Elevator Model

TD-200

TD-200

TD-300

TD-300

TD-300

Elevator motor power

3

3

4

5.5

7.5

Discharging screw conveyor

LS219*5

LS219*6

LS219*7

LS219*5

LS273*9

Pulse bag filter

MCD120

MCD160

MCD250

MCD450

MCD400*2
